| Quantity: | |
|---|---|
LDA-36
LIDE
As customized/Optional
Product Description
Product Description
Agricultural water belt irrigation PVC hose high pressure water pipe watering belt plastic coating 1 inch 2 inch 2 5 inch 3 inch
| Name | High Pressure PVC Hose |
| Material | high quality PVC and polyester thread |
| Size | See our data sheet or be customized |
| Color | Various for choose or be customized |
| Working Pressure | 2 bar to 10.5 bar |
| Packing | 100m each roll or as customized |
| Item | 3 inch Factory Price Plastic PVC Layflat hose Lay Flat Water Discharge Hose |
| Place of Origin | China |
| Weifang City, Shandong Province | |
| Brand Name | LIDE |
| Model Number | LDA-SD10 |
| Material | PVC and high quality fiber |
| Specification | 3/4'' to 12'' or as customized |
| Length | 100m/roll or as customized |
| Thickness | 1mm to 3.15mm or as customized |
| Standard | International Standard |
| Processing Service | Moulding, Cutting, Customized, OEM, ODM |
| Color | White/Yellow/Red/Blue/Green or as customized |
| Inner Diameter | 20mm/26mm/33mm/41mm/53mm/66mm/78mm/104mm/155mm/207mm or as customized |
| Application | Agriculture, Construction, Industry, Mining etc |
| Duty Type | Light/Middle/Heavy |
| Feature | Anti-UV, Sun-block, High Pressure |
| Raw material | Non-toxic PVC and fiber |
| Working pressure | 2 bar to 10.5 bar |
| Bursting pressure | 6 bar to 31.5 bar |
| Working temperature | -10 degrees to 65 degrees |
| Advantage | Anti-acid bases, aging resistance |
Application：
1. Designed for light and heavy duty applications
2. Used in agricultural equipment where continuous water flow through irrigation systems is required
3. water pump, pool & spa, construction, mines and marine
Colors for choose
The colors also can be customized as your request.
Our Advantages
We do everything possible to supply good quality goods for our customer.
Feature：
1.Lays Flat for easy, compact storage and transportation
2.Does not absorb water and is mildew proof
3.Resistant to grease, oil and many chemicals and acids
4.Reinforced with spiral plies and longitudinal synthetic cords for strength, durability, flexibility
5.UV Protected to withstand outdoor conditions,Non-toxic,No-smell
6.Assemblies and/or cut lengths available.
7.Burst pressure 3 times working pressure
Raw Material for the PVC Layflat Hose
PVC Granules and Polyester Fiber Yarn:
Water Hose Fittings Supply:
1. Hose nozzle sets
2. Hose reel/Hose car
3. Water Hose Brass Fittings
4. Layflat hose fittings
5. Air hose fittings
6. Hose clamp
Packing & Delivery
